Application Description :
- Pneumatic Auto Thread Trimmer Set.
- Suitable for all MTD4500 Series Machines, but only supply together with Machine head.
- Should be used together with AC servo motor or EC motor.
- Compressed air is necessary 6kg / cm or 70PSI）.
| UT | A 064(1/4) |
B 085(1/3) |
C 095(3/8) |
S 032(1/8) |
S1 064-254 |
|---|---|---|---|---|---|
| UT04□ | ● | ● | ● | ● | ● |
| UT04B | ● | ||||
| UT06A | ● | ||||
| UT09A | ● | ||||
| UT12A | ● | ||||
| UT17S | ● | ||||
| UT25S | *● |
Under bed thread trimmer
UT04A
UT12A
Thread Tension Set
UT04A
UT12A
LED Light ASM
TL002
Air wiper
Pneumatic Presser Foot Lifter
AL004
D D Direct drive servo motor
